Description
With a working height of 71 feet and useable both indoors and outdoors, the 6543 A trailer mounted boom is the most popular type of platform with skilled tradesmen and local communities. The compact and lightweight design makes them towable to any site, no CDL required. Hydraulic outriggers set-up in less than 30 sec for safe work on uneven ground.
Specifications
Manufacturer
Haulotte
Model
6543 A
Year
2026
Category
Aerial Work Platforms
Subcategory
Articulated & Telescopic Trailers
Power source
4 x 6 V 245 amp-hr
Lift capacity
500 lb
Turntable rotation
350° non-continuous
Jib - Vertical Motion
170° (+70 / -80)
Tow speed rating
65 mph
Leveling capability
12.5 °
Tongue weight (no options)
550 lb
Weight (no options)
7,700 lb
Working height
71 ft
Platform height
65 ft
Horizontal outreach (from centerline)
43 ft
Horizontal outreach (from edge of footpad)
37 ft
Up and over height
24 ft 2 in
Length - stowed
24 ft
Width stowed
5 ft 11 in
Height stowed
7 ft
Platform size
4 ft 1 in x 2 ft 9 in
Widest Point
15 ft
Jib - length
4 ft 3 in
Tire size
215/75R 17.5
